Product Description
GENERAL | |||||||
Overall Dimension | 11980mm*2500mm*4000mm(L*W*H) | ||||||
King Pin Setting | 1300mm | Dead Weight | 10000kg | ||||
RUNNING GEAR | |||||||
Suspension | Common mechanical or Air suspension | ||||||
Rim & Tire | Rim: steel disc, 8.0-20 or 8.5-20 Tire: 11.00-20 or 12.00-20 12units | ||||||
Axles | FUWA Or BPW axle, 13 tons load capacity | ||||||
Brakes | Dual lines pneumatic brake system; 30/30+30chambers, air-actuated | ||||||
King pin | Welded kingpin, size 50# (2'') or 90#(3.5") | ||||||
Landing Gear | 28T Manual operating,Heavy duty landing gear | ||||||
TANK | |||||||
Tank Volume | 45cbm | ||||||
Tank Material | Steel material Q235, Thickness 6mm | ||||||
Manhole Cover | 500mm manhole cover, 3 sets | ||||||
Compartment | Single | ||||||
Inner Fluidized Bed | Air bag | ||||||
KEY ACCESSORIES | |||||||
Air compressor | 0.2Mpa, 10cbm/Min | ||||||
Engine | Diesel engine 37KW, | ||||||
Air-charging system | 2'' main hole, 2''check valve, 1.5'' safe valve, 0.4Mpa gauge | ||||||
Discharge Pipe | 4''seamless steel tube | ||||||
Outlet discharging pipe | 4''rubber hose, 6m | ||||||
ELECTRICAL & PAINT | |||||||
Wiring | 24V, 6 lines | ||||||
Air/Elec. Connector | ISO standard air connector | ||||||
24V 7 pin plug socket | |||||||
Color | Upon request | ||||||
Painting | 1 coat of anticorrosive prime,twice coats of final paint | ||||||
Service
Factory Price
We are the direct factory for all kinds of good quality cement bulk trailers types with competitive price.
Customization
We have many experienced designers, according to your need to develop the most reasonable design and meet your customized needs.
Strict Quality Control
All semi trailers are inspected by our quality control department before shipped out.
Warranty
Our company promise one-year warranty period. You will get charge free accessories, if any damage of the accessories under normal use. The free accessories include axle, saddle, leaf spring, kingpin, landing gear, suspension, tire, air chamber and twist lock etc.
Leading time
Dry cement trailer delivery time is around 15 days.
24/7 Customer Service
Our after-sales staff will help you solve your problems as soon as possible. If you meet any technical problem, our technical engineer will guide you through your quality issues.
